CONFAST 5/8" (Inside/Screw 5/8"-11 Diameter) Drop-in Anchor Zinc Plated with 1 Setting Tool (25 per Box)

Price:

$ 171.32
  2. Shop
  3. CONFAST 5/8" (Inside/Screw 5/8"-11 Diameter) Drop-in Anchor Zinc Plated with 1 Setting Tool (25 per Box)
Japanese Silk Fabric Ceiling Light White Bedroom Close to Ceiling Lights Retro Vintage Flush Mount Ceiling Light Fixture Coastal Hallway Chandelier for Entryway
Japanese Silk Fabric Ceiling Light White Bedroom Close to Ceiling Lights Retro Vintage Flush Mount Ceiling Light Fixture Coastal Hallway Chandelier for Entryway
$ 219.99
$ 219.99
Clear Water Bottle Organizer,Stackable Bottle Storage Rack,4 Pack Wine and Tumbler Water Bottle Holder for Cabinet Organization and Storage,Plastic Wine Display/Drink Bottle Holder for Refrigerator
Clear Water Bottle Organizer,Stackable Bottle Storage Rack,4 Pack Wine and Tumbler Water Bottle Holder for Cabinet Organization and Storage,Plastic Wine Display/Drink Bottle Holder for Refrigerator
$ 72.48
$ 72.48

CONFAST 5/8" (Inside/Screw 5/8"-11 Diameter) Drop-in Anchor Zinc Plated with 1 Setting Tool (25 per Box)

http://gofinchkart.com/web/image/product.template/1162/image_1920?unique=b33a825
7 sold in last 24 hours
  • Can only be used in solid concrete
  • For use in dry, indoor applications
  • Designated diameter equals inside diameter
  • FLUSH MOUNT - Nothing sticks up above surface of the concrete

$ 171.32 171.32 USD $ 171.32

Not Available For Sale

($ 171.32 / Units)
8 people are viewing this right now
  • Color
  • Material
  • Size
  • Fastener Type
  • Brand
  • Product Type

This combination does not exist.

Mechanical Fasteners Drop-In Anchors
Contact Us
Tags

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Applications
The anchor is made from Carbon Steel, and is Zinc Plated. This anchor is designed for use in Concrete only, and should never be used in block or brick base material.
Environment
The anchor is designed for use in a Dry environment.

Hole Diameter/Bit Diameter
The anchor requires a 7/8" hole to be drilled in the base material (Concrete only). The hole should be drilled with carbide tipped bit that meets ANSI standards and used in a hammer drill.

Minimum Embedment
The minimum anchor embedment into the concrete is 2-1/2". Therefore, the anchor must be installed so that a minimum of 2-1/2" of the anchor is embedded into the concrete.

Spacing between Anchors
Each anchor must be spaced a minimum distance of 8-3/4" from each other when measured center to center.

Edge Distance
It is very important not to install the anchor any closer than 4-3/8" from an unsupported edge of the concrete.

Package Dimensions

7.95 x 3.66 x 2.72 inches; 8.59 Pounds

Technical Details
Color Silver
Material Carbon Steel Zinc Plated
Size 5/8"
Fastener Type Solid
Others
Brand Confast
Product Type Mechanical Fasteners
