Digital Multimeter,Multimeter Tester, High Sensitivity Voltmeter Ammeter Ohmmeter NCV Circuit Checker Measures AC/DC Voltage,AC/DC Current, Resistance, Diodes, Continuity, Transistor
- 【Safety】:This Digital Multimeter Ensures Accurate Measurements of AC/DC Voltage to 600v, AC/DC Current,AC Current MAX to 10A, Overload Protection On All Ranges To Ensure Long-Term Service Life
- 【Widely Used】:Accurate AC/DC Voltage, AC/DC Current, Resistance, Circuit Continuity Test, Battery Check, Diode/ Transistor Etc. Works as A Voltmeter, Ammeter, Ohmmeter, Car Battery Tester, Ampere Meters, Voltage Tester. Great To Check Household Outlets, Fuses, Batteries (Including Vehicles), Automotive Circuitry, Etc
- 【Backlight LCD】:Professional Multimeter Tester'S Display Is Visible From Different Angles, Making Value Easily Readable In Low Light and Dark Places. Data Hold Function Makes Measuring Easier
- 【Non -Slip And Bracket】:Our Multi Meter Can be Hand Held Or Stood Using Its Fold Out Stand. Removable Thick Rubber Cover Is Made of Kind of Non-Slip Slightly Soft Plastic That Will Help With Drop Protection and Minor Bumps Protection
- 【After -Sales and Packaging】:Prioritize Customer Satisfaction ,If You Have Any Questions or Concerns, Our Dedicated Support Team Is Always Ready to Assist You. Package Includes 1 Multimeter, 2 Test Leads, 2 AA Batteries, And A User Manual
| Specification Met | IEC, Ce Rated |
| Compatible Devices | Household electrical devices, vehicle electrical systems, and other devices with electrical components |
| Manufacturer | coczow |
| Brand | coczow |
| UPC | 707443344028 |
| Number of Items | 50 |
| Included Components | Battery |
| Power Source | Battery Powered |
| Upper Temperature Rating | 40 °C |
| Colour | Black |
| Style | Compact |
| Item Weight | 381 g |
| Part Number | PM8233D+ |
| Model | PM8233D+ |
| Measurement Type | Multimeter |
| Maximum Operating Voltage | 600 Volts |
| Style Name | compact |
| Item Dimensions | 6.54 x 3.07 x 2.52 inches |
| Product Type | Multi Testers |
| Minimum Operating Voltage | 200 Millivolts |
-
Save 10% when you buy two or more items.
-
Get 5% off your next purchase.
-
Enjoy free delivery on orders above $200.
-
Orders are processed and shipped from Washington
3-6 days (Domestic)
Confidence-backed purchases with 30-day return support.
USD |
BRSW2AIZDIOQIYIZ |
Category |
Electrical , Testers , Multi Testers |
Tags |
Estimated shipping
Select a product to estimate shipping.The multimeter adopts a 15 mm high LCD with backlight, which can clearly read out the disply even in dark places. It is a portable 3 1/2 bit automatic range digital multimeter with high performance and high reliability. The whole circuit is based on integrated circuits, equipped with overload protection circuit, can be used to measure AC and DC voltage, AC and DC current, resistance, capacitance, frequency, diode,continuity test and NCV test. It can be widely used in schools, research insitutes, factories,enterprises and other social fields.
Product Specifications
Auto Range and Maximum Measurement
Overload Protections: PTC Proctection
Large Backlit Display and Data Hold
Protective Shell with Pen Slot and Stand
Additional Features with NCV Auto Power Off
Sworely Auto-Ranging Digital Multimeter
Technical Specifications
DC Voltage: *200mV/2V/20V/200V ±(0.5%+2) *600V ±(0.8%+2)
AC Voltage: *200mV*2V/20V/200V ±(1%+3) *600V ±(1.2%+3)
DC Current: *200μA/2000μA/20mA/200mA/10A ±(1.5%+3)
AC Current: *200μA/2000μA/20mA/200mA/10A ±(1.5%+4)
Resistance: *200Ω/2kΩ/20kΩ/200kΩ ±(0.8%+2) *2MΩ/20MΩ ±(1.0%+2)
Frequency: *20kHz ±(1.5%+5)
Capacitance: *20nF/200nF/2μF/20μF/200μF/2mF±(4%+5)
Power Supply: 1.5V AAA Battery
Operating environment: 0-40°C / 32-104°F <80%RH
Storage environment: -10-50°C / 14-122°F <70%RH
Safety: IEC61010 -1600V CAT III
Large Backlit LCD Display
The large LED backlights enables it to see numbers easily and quickly; The bright backlight makes the readings visible in dimly lit areas and at night.
Low Battery Indication
There is a low battery indication on the screen to remind you to replace the battery in time, so as to avoid affecting the work efficiency due to low power.
Auto Power Off
If the meter is not in operation for 15 minutes, it will turn off automatically. To turn it on again, simply push HOLD/BL button.
NCV Detection
This Clamp Meter features non-contact voltage testing with a sound and light alarm. When the indicator light is on, it means there is voltage, please pay attention to your safety
Durable Protective Shell
The case is made of some kind of slightly soft plastic that provides drop protection, making the multimeter more durable.
Convenient Battery Replacement
Built-in 1 9V battery, it can last longer and provide convenient battery replacement.
Convenient Alligator Clips
The alligator clip is rugged and can grip the subject tightly for easy testing.The maximum opening width is 0.54 inches
Data Hold
You can use the data hold function to freeze the data being displayed on the digital display.
Short press the Hold button: hold reading, press again to release hold reading.
