Norton 1601 Series Door Closer, Tri-Style (Regular, top jamb, or Parallel arm), Non-Handed, Size 1-6, Cast Aluminum (1601-689)
6 sold in last 24 hours
- Norton 1601 Series, Grade 1 certified & UL / cUL listed for use on fire rated doors and positive pressure fire test. ADA Compliant.
- Recommended on commercial interior or exterior doors including: Aluminum Storefronts, Office Doors, Utility Closets, and Storage Rooms.
- Non-Handed for installation on right- or left- hand swing doors.
- Exceeds 25 million cycles. Covered by Norton End-of-Life Recycling Program
- 25-year limited warranty
Tags |
The 1600BC Series door closers offer proven quality, performance and reliability unmatched by the competition. A staple in the industry, these ANSI/BHMA Grade 1 closers are designed for exterior or interior doors.
All Closers are full rack-and-pinion types with cast aluminum alloy body and are non-handed to permit installation on doors of either hand. The Closer fluid contains lubricity and anti-oxidation agents maintaining stable viscosity to allow door closer to perform in temperatures ranging from extremely high to as low as -40°F.
Typical Applications: Recommended on interior or exterior doors including: Aluminum Storefronts, Office Doors, Utility Closets, Storage Rooms.
FEATURES:
• full rack-and-pinion type with cast aluminum alloy shell, • heavy duty cast aluminum body, • Spring Adjustable sizes 1 - 6. • Maximum degree of swing is 180°, trim permitting. • Tri-style packaging: regular, top jamb or parallel mounting, • Non-handed for installation on right- or left- hand swing door, • 2-7/8" projection.
BENEFITS:
• High strength aluminum alloy closer body provides for long life, • Exceeds 25 million cycles, • Longer life results in fewer replacements and less material used, • Covered by Norton End-of-Life Recycling Program.
Color: 689 Aluminum.
CERTIFICATIONS- Code Compliance:
• ANSI/BHMA A156.4, Grade 1 certified, • UL / cUL listed for use on fire rated doors, • UL10C listed for positive pressure fire test, • Meets requirements for Americans with Disabilities Act (ADA) and ANSI/BHMA standard A117.1
WARRANTY: 25-year limited warranty.
| Main Specification | |
|---|---|
| Specification Met | Ul or Cul or Ada |
| Manufacturer | Norton-Assa Abloy |
| Exterior Finish | Aluminum |
| UPC | 736530884000 |
| Product information | |
| Product Dimensions | 12 X 2.5 X 4 Inches |
| Technical Details | |
| Material | Aluminum |
| Item Weight | 6.85 Pounds |
| Shape | Rectangular |
| Part Number | 1601-689 |
| Item Package Quantity | 1 |
| Batteries Required? | No |
| Batteries Included? | No |
| Thickness | 3 Inches |
| Measurement System | English/Standard |
| Brand | Norton-Assa Abloy |
| Installation Type | Screw-In |
| Size | Norton 1601 |
| Color | Cast Aluminum (689) |
| Item model number | 1601-689 |
| Item details | |
| Recommended Uses For Product | Commercial Interior Or Exterior Doors or Aluminum Storefronts or Office Doors or Utility Closets or Storage Rooms |
| Others | |
| Product Type | Door Closer |
