LSDA L100 Series Keyed Grade 2 Leversets - Commercial Medium Duty (Satin Chrome, Entrance)
9 sold in last 24 hours
- Entrance/Office (L100): Pushing and turning inside button locks outside lever requiring use of key until button is manually unlocked. Pushing inside button locks outside lever until unlocked with a key or inside lever is turned. Inside lever always retracts the latch.
- Storeroom (L140): Outside lever never retracts the latch. Entrance by key only. Inside lever always retracts the latch.
- Classroom (L150): Classroom. Outside lever is locked and unlocked with a key in the outside cylinder. The inside lever always retracts the latch.
- ANSI/BHMA certified A156.2 Series 4000, Grade 2 ADA Compliant
- UL Listed for 3 hour fire door
Tags |
L100 Series Leversets – Grade 2 Standard Duty The L100 Series is a complete line of Grade 2 commercial leversets. Built with independent return springs in each lever and with an optional clutch feature to protect against excessive torque, these levers resist sagging. The L-shaped lever design with less than 1⁄2” gap between the handle and the door meets most accessibility codes. Certifications: ANSI/BHMA certified A156.2 Series 4000, Grade 2 ADA Compliant UL Listed for 3 hour fire door as noted Specifications: Door Thickness: 1-3/8” to 1-7/8" Door Preparation: 2-1/8" diameter bore required Backset: 2-3/4” Handing: Non-handed Strike: ANSI 4-7/8” x 1-1/4” full lip standard Warranty: 15 year limited mechanical warranty 1 year finish warranty from date of purchase
Package Dimensions
9 x 9 x 9 inches; 3.9 Pounds
| Main Specification | |
|---|---|
| Specific Uses For Product | Door |
| Brand | Lsda |
| Product information | |
| Color | Satin Chrome |
| Technical Details | |
| Exterior Finish | Chrome |
| Special Feature | Easy To Install |
| Others | |
| Product Type | Hardware Handle |
